Rating:P1(0.1A 48VDC/125VAC 可选镀金Gold plated optional)
03(1A/3A 125VAC)
Operating Frequency:Electical(10~30次/分 cycles/minute)
Mechanical(120次/分 cycles/minute)
Contanct Resistance(Initial Value):100MΩ Max(取决于类型/Depends on P/Ns)
Insulation Resistanc(at 500VDC):在500VDC时/at 500VDC,100MΩ Min
Dielectric Strength:AC 600V RMS(50-60Hz)
Storage Temperature:-40℃ - +85℃
Storage Humidity:85%RH Max
Service Life:Electrical(6,000~100,000次/cycles(取决于类型/Depends on P/Ns)
Mechanical(1,000,000次/cycles)
Unit Net Weight:约0.5(直PCB无手柄类型)About 0.5g(Straight PCB type without lever)
