Rated Load: 0.1A at 12VDC, 5mA at 10VDC
Operating Frequency: Electrical: 10–30 cycles/min, 1–500 mm/s; Mechanical: 120 cycles/min
Initial Contact Resistance: 100 mΩ Max.
Insulation Resistance: 100 MΩ Min.
Dielectric Strength: Between terminals: AC 500V
Between terminals and housing: AC 1000V
Operating Temperature: -40°C to +125°C
Electrical Life: 300,000 cycles
Applications: Automobiles, Motorcycles, Home Appliances
