Technical Parameters
| Specification | IF Series |
| Contact Rating | AC 125V 6A,AC 250V 3A,DC 28V 3A |
| Mechanica Life | 100,000 make-and-break cycles |
| Contact Resistance | 10mΩ max. |
| Insulation Resistance | 500MΩ min/500VDC |
| Dielectric Strength | 1,000 Vrms min.@sea level.(initial value) |
| Operating Temperature | -40℃ to 80℃ |
| Materials | |
| CASE: | Diallyl phthalate (DAP) (UL94v-0). |
| ACTUATOR: | Brass, chrome plated. |
| BUSHING: | Brass, nickel plated. |
| HOUSING: | Stainless Steel. |
| SWITCH SUPPORT: | Brass, tin plated. |
| CONTACT / TERMINALS: | Brass with silver or gold plated. |
Product Description：
The 1F Series toggle switches are available in SPDT, DPDT, and other configurations, offer waterproof protection, and have a switch life of up to 100,000 cycles.
Product Advantage
1. Long lifespan: 100,000 cycles
2. Can achieve waterproof functionality
3. Multiple handle types available: square handle, round handle, etc., to meet different customer needs
4. Options for reset and self-locking functions, providing multiple options to meet customer requirements
Application:
Heavy-duty industrial remote controls.
Marine instruments and equipment.
Audio amplifiers
