Technical Parameters
| Specification |
| CONTACT RATING: | 3 Amps with resistant load @ 120VAC or 28VDC 1 Amps with resistant load @ 250VAC 0.4 Volt - Amps ( VA ) max. @ 20V max. ( AC or DC ) |
| MECHANICAL LIFE: | 30,000 make-and-break cycles. |
| CONTACT RESISTANCE: | 20 mΩ max. (initial value) @ 2-4VDC 100mA for both silver and gold plated contacts.
|
| INSULATION RESISTANCE: | 1,000 MΩ min./1000VDC |
| DIELECTRIC STRENGTH: | 1,000 Vrms min.@sea level.(initial value) |
| INGRESS PROTECTION: | IP67(In house test) |
| OPERATING TEMPERATURE: | -30°C to 85°C |
| Materials |
| CASE & BUSHING: | Glass filled nylon 6/6, flame retardant, heat stabilized (UL94v-0) |
| ACTUATOR: | Brass with chrome plated, internal o-ring sealed. |
| SWITCH SUPPORT: | Brass， tin plated. |
| CONTACT / TERMINALS: | Copper with silver or gold plated. |
Product Description：
The 2B Series Rocker Switch is a compact SMD switch rated to IP67 that offers a variety of switching functions.
Key features：
Compact SMD design: Space-saving surface-mount construction ideal for automated assembly and dense PCB layouts.
High protection rating: IP67-rated waterproofing ensures reliable performance in harsh or wet environments.
Versatile switching functions: Offers a variety of switching options to suit different application requirements.
Application:
Telecommunications equipment.
Instrumentation and testing equipment.
Medical equipment.
