Technical Parameters
| Specification |
| Operating temperature range： | -30°C to 80°C. |
| Rating： | 5.5V DC |
Output Voltage (Proportional Output)： | Operating range: Typically 10% to 90% of VDD |
Voltage divider error： | Center voltage: 40%–60% of VDD |
| OPERATING TEMPERATURE: | -40°C to 85°C. |
| Insulation Resistance： | 100 MΩ min./DC250V |
Joystick control angle： | Maximum effective angle: 30° ± 3 |
Joystick force： | 0.5±0.4N ≈ 50±40gf |
| Lifes： | 2,000,000 Cycles |
| Basic Information |
Handle Material: | Metal handle |
Installation Method: | Panel Installation |
Terminal Type: | Flat cable (silicone cable) |
Product Description
1. Precise positioning and responsive performance; made from high-quality plastic and metal, with a lifespan of up to 2 million rotations;
2. Comes with a detachable cable for easy replacement; precision bearings ensure a superior user experience;
Applications
Small controller, ground control station, water-based control module and so on.
