4A

Technical Parameters

Specification
Rating	3 Amps with resistant load @ 120VAC or 28VDC 1 Amps with resistant load @ 250VAC 0.4 Volt - Amps ( VA ) max. @ 20V max. ( AC or DC )
MECHANICAL LIFE:	30,000 make-and-break cycles.
Contact Resistance	20 mΩmax. (initial value) @ 2-4VDC 100mA for both silver and gold plated contacts.
Dielectric Strength	1,000 Vrms min.@sea level. (initial value)
OPERATING TEMPERATURE:	-40C to 85°C.
Insulation Resistance	1,000 M Ω min./1000VDC

Materials
CASE & BUSHING	Glass filled nylon 6/6, flame retardant, heat stabilized (UL94V-0).
ACTUATOR:	Black nylon, internal o-ring sealed.
SWITCH SUPPORT:	Brass or steel, tin plated.
TERMINAL/CONTACT:	Copper with silver or gold plated.

Product Description

The 4A Series miniature toggle switches feature an IP67 waterproof rating, a maximum current rating of 3A, SPDT and DPDT configurations.

Key Features

High waterproof rating: Features IP67 protection, making it dust‑tight and resistant to temporary immersion, suitable for harsh or outdoor environments.
High current rating: Rated up to 3A, offering strong load capacity for a miniature rocker switch.
Flexible circuit configurations: Available in SPDT and DPDT options to meet single‑pole or double‑pole control requirements.
Clear operation identification: Actuator cap can be marked with symbols such as “OI” for easy status recognition, enhancing usability and safety.

Applications

Telecommunications.

Testing equipment.

Computers and peripherals.
