Specifications
Rated Capacity: 0.4 Volt-Amps (VA) max. @ 20 V max (AC or DC)
Power: Dependent upon contact material
Mechanical Life: 100,000 make-and-break cycles.
Electrical Life: 50,000 cycles.
Contact Resistance: 10 mΩ max. initial @ 2–4 VDC, 100 mA for both silver and gold-plated contacts.
Insulation Resistance: 1,000 mΩ min.
Dielectric Strength: 1,000 V RMS @ sea level.
Operating Temperature: -30°C to 85°C.
Torque: 0.8 Nm max. applied to unit.
Panel Thickness: 6 mm max., 2 mm min.
Materials
Waterproof Rating: IP67
Applications:
Industrial controllers, industrial control panels
