Operating temperature: -40°C to +85°C.
Actuation force: Max. 23 N
Terminal bracket: PBT, UL94V-0, black
Shield: C2680, T = 0.20 mm, nickel-plated across all areas
Housing: PBT, UL94V-0, black
Terminals: Phosphor bronze C5210, T = 0.35 mm, contact area gold-plated 6U
Durability: Minimum 750 cycles
Storage temperature: -40°C to +85°C
Mechanical: All critical dimensions marked with “*”
