SPECIFICATION:
1.Electrical characteristics
1-1.Current rating:
Signal(Pins2,3,4):DC 0.5A max.
Power(Pins1,5):DC 1.8A
1-2.Voltage rating:AC 30V.
1-3.Contact resistance:
30MΩ max(initial)
50MΩ max(After Durability)
1-4.Insulation resistance:100MΩ min. at 500V DC.
1-5.Withstanding voltage:100V AC for 1 minute.
2.Mechanical characteristics
2-1.Life test:5000 cycles min,
2-2.Mating force:35N Max
Unmating force:8N Min(initial)
6N Min(after life test)
3.Temperature range:-40~℃~+80~℃
4.Dustproof and waterproof grade:IP67
