Technical Parameters
| Specification | |
| Rating | 25mA,24V DC |
| Operating temperature | -40 °C to 85 °C |
| Contact Resistance | 50 mΩ Max. |
| Insulation Resistance | 100MΩ Min. 100V DC |
| Operating Life | 2,000 cycles |
| Dielectric Strength | 500V AC / 1 minute |
| Travel | 2mm |
| Operating Force | 1000gf Max. |
Product Advantage
1. Both ON/OFF position applicable for soldering process.
2. Gold contact for high reliability.
3. Red、Blue and Black color options.
4. Multiple gear options are available.
Key Features
Side actuation
Gold contact for high reliability
Red, blue, and black color options.
Applications
Industrial control
Computers and peripherals
Variety of function controls
