Technical Parameters
| Specification |
| Rating | 25mA, 24V DC |
| MECHANICAL LIFE: | 2000 make-and-break cycles. |
| Contact Resistance | 50 mΩ max. |
Dielectric Strength
| 500V AC/1 minute |
| OPERATING TEMPERATURE: | -40°C to 85°C. |
| Operating Force | 800gf max. |
| Insulation Resistance | 100 MΩ min./500VDC |
Product Description
The switches in the EP(I)(M) series are piano-key encoder switches
Key Features
*Side actuation
*End stackable
*Through hole or SMT
Applications
Industrial control
Automatic machines control
Telecommunication
