SPECIFICATION:
1.Electrical characteristics
1-1.Current rating:DC 0.5A max.
1-2 Voltage rating:DC 30V.
1-3 Contact resistance:50MΩ max
1-4.Insulation resistance:1000MΩ min. at 500V DC.
1-5.Withstanding voltage:500V AC for 1 minute.
2.Mechanical characteristics
2-1.Life test:5000 cycles min,
2-2.Mating force:3~30N
Unmating force:3~30N
3.Temperature range:-40~℃~+80~℃
4.Dustproof and waterproof grade:IP67
