Operating Principle: Absolute
Rated Power: DC: 10V 10mA
Number of Mechanical Positioning Steps: 16
Rotational Force: 700±200 gf·cm
Resolution: 16 signal outputs, with each position corresponding to a unique set of signals
Withstand Voltage: AC 50V for 60s±5s
Contact Resistance: MAX 500 mΩ
Insulation Resistance: MIN 100 MΩ
Rotation Angle: 360° continuous cycle
Operating Temperature: -40°C to +85°C
Rotation Life: Over 40,000 cycles
