Product Specifications:
Mechanical life: > 100,000 operations
Operating tolerance: < 15 cycles/minute
Protection rating: IP 65
Panel thickness: 0.8 mm to 4.5 mm
Installation Torque: 0.88 N·m
Maximum Insulation Voltage: 1500 V, 60 Hz, 1 minute
Storage Temperature: -40°C to +85°C
Operating Temperature: -25°C to +70°C
Contact Resistance: ≤50 mΩ (initial)
Vibration: 10–500 Hz, amplitude 0.35 mm
